USBDM-1-JS16 features: • A single BDM for programming and debugging HCS12(X), 9S08 and Coldfire V1 microcontrollers • Includes a 3.3V (500mA) regulator and can supply 5V or 3.3V to the target board (jumper selectable). This is useful when debugging or programming a target board without power supply. • Includes a voltage level monitoring circuit with a red LED indicating 5V and a yellow LED indicating 3.3V. This unique feature is only available with Wytec's USBDM.
• I ncludes a resettable fuse to protect the USB port of your PC. • Compact size, 0.8' x 2.4'. The installation steps are as follows ( Do not plug in the USBDM-1 until the step 3 ): 1. You need to install the CodeWarrior version 5.1 in order to use the USBDM-1 for the HCS12. If you have not installed the CodeWarrior you need to download and install the Code Warrior 5.1. Freescale recently removed the MC9S12DG256 used in many 3rd party boards from the new version 5.2, but kept the MC9S12DG128 used in their own Tower Systems.
If you have trouble to find the version 5.1, just email us and we will get it for you. The size of the file is very large. Delphi Ds150e Software 2017 on this page.
FLASH/EEPROM programming and debugging through an RS-232 serial. Freescale Semiconductor, Inc. A2 Racer 2 Torrent there. To change the contents of this protected block is to use a BDM-based.
It will take a few hours to download, so you should first save it on your hard drive in case you need to install it in another PC in the future. Click, then click Browse All Files, click the version 4.10.6, then download the USBDM_4_10_6_250a_Win.msi. It may be better to use this version for the HCS12. The newer version works for CW, but does not work for pgo's flash_programming utility. Pgo's flash_programming utility is very handy. You can use it to check if your new hardware can communicate with the USBDM. If it can, your mcirocontroller circuit is working.
After download, click the installer, USBDM_4_10_6_250a_Win.msi, in the folder named Downloads, the installation will be done automatically. In the Device Manager, check the Universal Serial Bus devices, it should show WinUsb Device.
